Nissan Xterra

This suspension kit was designed for the extreme off roader. This kit is fully CAD designed with 3/16” and 1/8” boxed plate. We changed the upper arm mounting location to improve the geometry of the full suspension cycle. This kit is capable of 19” of wheel travel with the 2WD system and 17” of wheel travel with the 4WD system. The 4WD kit comes with 300M race axles. It allows for the use of tires up to 37” in diameter and designed to run a 2.5 x 10” coilover and bypass shock with +1” rod ends.  **Note: This system does require fabrication work. We highly recommend to have the work done by a professional and qualified fabricator. This kit requires Titan hubs and brakes. We recommend 04-06 brakes for the Frontier to avoid rim spacing issues. 4wd requires the use of a Titan front differential and Titan CV's **

Specs:
Wheel Travel: 2WD 19”/ 4WD 17”
Minimum Rim Size: 17”
Maximum Tire Size: 37”
Track Width: 8” Wider Per Side
Coilover: 2.5 x 10” with +1” Rod Ends
Bypass: 2.5 x 10” with +1” Rod Ends

What’s Included:
Boxed UCA
Boxed LCA
Spindles
Billet Tie Rods
UCA/ Shock Mounts
Grade 8 Hardware
DOT Stainless Braided Brake Lines
Black Powder Coat
Extended 300M Axles (4WD Kit Only) (Axles Only Work with OEM CV’s)
Stainless Misalignments
All Needed Heims and Uniballs



Shipping cost will be sent separately due to weight

FRONTIER 05+ FRONT 2.5 DIA. REMOTE RESERVOIR COIL-OVER

King's OEM Performance Upgrade Kits provide a bolt on suspension system that dramatically improves your on and off-road performance. Our kits are designed to maximize wheel control by damping every inch of shock movement in a smooth and calculated manner, allowing the driver to obtain more control over the vehicle. Each kit has been subjected to extensive dynamometer lab testing as well as punishing real world testing to develop the optimal damping curve for each vehicle. Every kit is hand built in the USA with top of the line materials machined to precise tolerances and assembled by our experienced shock technicians. All King'shocks have the ability for custom valve adjustments with simple hand tools and are designed to emulate the performance and tunable design of our high end race shocks. All of our OEM Performance Upgrade Kits come complete and provide all necessary hardware as well as detailed instructions for installation on your vehicle. Along with the durability to last longer than any factory equipped option, King'shock?s completely serviceable design allows them to be fully rebuilt after many years of extreme use. See what a difference a set of King'shocks can make on your vehicle. Our experienced shock technicians are always a phone call away to help should any questions arise during installation or use. Nothing rides like a king.
