Nissan Frontier

This kit is a true bolt-on long travel kit. It’s fully CAD designed with 3/16” and 1/8” boxed plate. The kit is 3"" wider per side for a total of 6"" wider front track width. Compatible with both 2WD and 4WD. Bolts up to the stock spindle. Cycles 14"" wheel travel. This kit is meant to be paired with our custom made bolt-on 2.5"" Radflo coilover.  Comes with limit straps. The top mount does need to be welded to the frame for the limit straps to work. 4WD comes with a pair of 300M axles to complete the kit. (Axles only work with OEM CV's)

Specs:

Wheel Travel: 14” Minimum Rim Size: 17” Maximum Tire Size: 37”

Track Width: 3” Wider Per Side

Coilover: Custom Radflo 2.5” with Reservoirs

What’s Included:

Boxed UCA

Boxed LCA

Billet Tie Rods

Grade 8 Hardware

DOT Stainless Braided Brake Lines

Black Powder Coat

Extended 300M Axles (4WD Kit Only) (Axles Only Work with OEM CV’s)

Stainless Misalignments

Limit Straps

All Needed Heims and Uniballs

Replaces the outer tie rod/ ball joint. This kit will tighten up the front end and steering. Connects to the stock inner tie rod. Runs a heim outer.
Specs:

2020+ models
Stock Replacement
Bolt-On

What's Included:

Sold in pairs
Billet Tie Rods
Stainless Misalignments
Grade 8 Bolts
All Needed Heims

B8 Control Arms are a direct fit upgrade for factory upper control arms on trucks and SUVs. The kit contains a pair of control arms which correct the caster alignment for better straight line stability with lifted suspensions, and the improved pivot angles increase wheel travel and reduce stress on the joints. These strong black powder-coated 4130 chromoly steel arms are a tubular design which allows for more spring and shock clearance and feature greasable polyurethane bushings and heavy duty ball joints for the ideal combination of ride quality and durability with minimal maintenance needed. They come with detailed instructions and all necessary hardware for easy installation and are compatible with all Bilstein shocks and coilover kits. All components are replaceable.

Fully CAD designed 4” lift spindles. Vertical 1” uniball in spindle for upper arm mount. Boxed UCA. This kit allows for increased wheel travel. Comes with heim outer steering. When paired with a lift coilover, this kit is capable of 6” of lift. This kit will increase the track width 1” per side due to hub placement. This kit is the best way to get lift yet retain the factory ride.
Specs:
Lift: 4”
Minimum Rim Size: 16”
Maximum Tire Size: 33”
Track Width: 1” Wider per Side

What's Included:
Lift Spindles
Boxed UCA
Billet Heim Steering
DOT Stainless Braided Brake Lines
Stainless Misalignments
Grade 8 Hardware
All Needed Heims and Uniballs

CJD Racing fabricated shock mount with integrated UCA mounts

Allows up to 14" wheel travel on a Titan swap setup with an 8" travel coilover and +1" longer rod end and the correct suspension components

Made from 3/16" plate steel

Included:

Driver and passenger side mounts

Grade 8 hardware

Install instructions

***Suggested install by experienced fabricator***

***Adjustable heim UCA's suggested***

Tired of breaking those cheap plastic grab handles? CJD Racings Nissan Aluminum Grab Handles solve that problem in fashion.

Details

- 6061-T6 Aluminum

- Mounting Hole Length 9 13/16"

- CNC Machined

- Raw Aluminum Finish

FOX's 2.0 Performance Series IFP (Internal Floating Piston) smooth body shocks for trucks and SUVs provide a comfortable on-road ride and predictable off-road handling in even the toughest conditions via their proven damping technology¿a race-developed, high-flow damping piston matched with application-specific valving.

The precision metal impact aluminum body increases cooling capacity and resists rust. FOX's IFP separates the shock oil from the high-pressure, nitrogen-charged gas chamber. This eliminates oil aeration for maximum performance from the factory-tuned precision valving.

Features and Benefits

• Direct replacement for stock and aftermarket lift kits
• 2-inch metal impacted 6061-T6 aluminum body resists rust
• Clear anodized for a durable finish
• Internal IFP monotube reservoir design separates shock oil from the high-pressure nitrogen
• 5/8-inch hard chrome-plated, heat-treated alloy steel shaft
• Redundant sealing pack system main seal, wiper seal, scraper seal
• JM92 Advanced Suspension Fluid for improved performance at variable temperatures
• Quiet nitrile rubber bushings for increased suspension articulation

FOX PERFORMANCE SERIES 2.0 COIL-OVER IFP SHOCK - 983-02-054

FOX Performance Series shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable off-road handling in even the toughest conditions.

• Performance Tuned For Vehicle Specific Application
• Aluminum Body Dissipates Heat Faster Than Steel
• IFP Separates Oil From High-Pressure Nitrogen Gas
• Black Anodized CNC Machined Aluminum Components

Tech Specs:

• Shock Type: Coil-Over Shock
• Reservoir Type: Internal Floating Piston (IFP)
• Travel: 4.19 Inches
• Compressed Length: 11.50 Inches
• Extended Length: 15.69 Inches
• Diameter: 2.0 Inches
• Product Series: Performance

Ditch the problematic stock breather! The stock breather is a major failure on these vehicles.  Extend the life of your axle seals and gears with these breather kit.

Getting moisture in your differential is a bad idea. When you open a differential that is filled with water you will find milky running oil that is clearly incapable protecting your gears. Many factory axles have a breather raised much higher than water is expected to reach.

When you do an axle swap you should consider whether your axle will suck in fluid when it crosses water. Don't take the risk! Use our axle housing breather kit on your Nissan axles.
Kit Includes:

• 5' or 8' option of High Quality Rubber Fuel Hose

• Brass Barb Fitting with Nissan Thread. Tapered thread for a tight fit to axle housing.
• Optional K&N filter
